NightRide PRO-SL S04/S14 (Bowl) 640

The NightRide Pro-SL S04/S14 (Bowl) 640 is a high-resolution thermal imaging system with Ethernet and Wi-Fi connectivity, designed for professional-grade vehicle integration. Compact and rugged, it provides advanced thermal awareness across mission-critical operations.

Built with a 640 x 512 thermal sensor and a 28° field of view, the Pro-SL S04/S14 (Bowl) 640 detects heat signatures beyond a quarter mile—even in rain, snow, fog, dust, or smoke. Installation is simplified using the Unity S04 or S14 Spotlight Mount with replacement bowl and handle. Connectivity includes Wi-Fi hotspot or Ethernet streaming, with optional HDMI adaptor for monitor integration. The system supports continuous or event-based recording, with mechanical pan/tilt for expanded coverage. Engineered with IP67 sealing and low 3W power consumption, the Pro-SL is built to endure extreme operational environments.

NightRide Pro-SL delivers tactical superiority by detecting heat signatures beyond a quarter mile under any conditions. Whether used in enforcement, firefighting, search and rescue, or emergency management, it provides operators with critical seconds to anticipate and respond effectively.

Main Features

• High-resolution 640 x 512 thermal imaging
• Unity S04 or S14 Spotlight Mount
• Quick installation with replacement bowl
• Wi-Fi hotspot or Ethernet connectivity
• Optional HDMI adaptor for monitor connection
• Mechanical pan/tilt functionality
• Always recording or event-based recording
• Acts as access client to in-vehicle router
• IP67 sealed design

Specifications

• Dimensions: 9 ½" x 6 ½" x 3"
• Weight: 9 oz (0.56 lbs)
• Operating Temperature Range: -40°F to +140°F
• Sealed Design: IP67
• Sensor Type: 640 x 512 thermal sensor
• Field of View: 28° (H)
• Frame Rate: 25hz
• Power Consumption: 3W
• Power Requirements: 12–16 VDC

Range

• Detection: 660 yds
• Recognition: 180 yds
• Identification: 90 yds

Accessories

• Coiled PoE Cable
• Passive PoE Splitter
• Cigarette to Barrel Cable
• Heat Shrink Tubing
• User Manual
