NightRide PRO-SL S04/S14 (Bowl) 384 w/ Ethernet

Equipped with a 384 x 288 thermal sensor and a 28° field of view, the Pro-SL S04/S14 (Bowl) 384 detects heat signatures beyond a quarter mile through adverse conditions including rain, snow, fog, smoke, and dust. Using the Unity S04/S14 Spotlight Mount and replacement bowl, installation is quick and secure. Connectivity is handled through Wi-Fi hotspot or Ethernet (wired) streaming, and the system offers continuous or event-based recording. With mechanical pan/tilt control, rugged IP67 sealing, and efficient 3W power consumption, this unit is engineered to withstand extreme environments while delivering reliable thermal imaging.

NightRide Pro-SL provides a discreet tactical advantage—delivering visibility beyond a quarter mile in nearly any condition. Whether for law enforcement, rescue operations, firefighting, or emergency management, it gives operators the critical

Main Features

• Standard-resolution 384 x 288 thermal imaging
• Unity S04 or S14 Spotlight Mount
• Quick installation with replacement bowl
• WiFi + Ethernet (wired) connection to phone, tablet, or laptop
• Mechanical pan/tilt functionality
• Rugged IP67-sealed design

Specifications

• Dimensions: 9 ½" x 6 ½" x 3"
• Weight: 9 oz (0.56 lbs)
• Operating Temperature Range: -40°F to +140°F
• Sealed Design: IP67
• Sensor Type: 384 x 288 thermal sensor
• Field of View: 28° (H)
• FPS: 25hz
• Power Consumption: 3W
• Power Requirements: 12-16 VDC

Range

• Detection: 480 yds
• Recognition: 120 yds
• Identification: 60 yds

Accessories

• POE Kit
• Heat Shrink Tubing
• User Manual
